China Security Surveillance Analog HD 5MP Ahd Bullet Camera

Product Description

Feature:
• AHD output
• 1/2.5'' 5.0MP CMOS
• Resolution: 2592 x 1944 , 5.0 Megapixels
• Minimum illumination:0. Lux/F1.2(0Lux IR ON)
• IR Distance: 15-25M
• IR Cut function, Day@night Surveillance
• Non coding compression, High Efficiency, without delay real-time transmission
• Up to 500 meters lossless transmission with 75-3 coax

Specification:

Model	BA-WK2850EA
Camera
Image Sensor	1/2.5" 5.0 Megapixel CMOS
Solution	NVP2475+K03
Effective Pixels	2560(H)x1944(V)
Electronic Shutter	1/50s ~ 1/60,000s
Video System	PAL/ NTSC
Video Frame Rate	AHD 20 fps@2560×1944P
Video Output	1CH, AHD
Smart IR control	Support
Min. Illumination	[email protected](AGC ON), 0Lux IR on
Day/Night	Auto/Color/(B/W)
White Balance	Auto
Other	AWB,AGC,BLC
IR Led
IR Led	¢5X28PCS
IR Distance	15-25M
Lens
Focal length	Fixed lens 3.6/6mm
General
Power Supply	12 VDC ± 10%
Power Consumption	< 5 W
Operating Temp.	-30ºC-(+60)ºC, 10%-90%RH
Transmission Distance	Over 300m via 75-3 coaxial cable
