Guangtai Full C-Band or L-Band Tunable Optical Laser Source Lts-2000
Product DescriptionThe LTS-2000 series full C-Band or L-Band quick adjustable laser optical source , is a 2U small model of high precision and muti-function, can be set up 1~4 port independent C or L band adjustable optical source. Various flexible configurations optional (see more in product series......
Send Inquiry
Product Description
LTS-2000 big color displays, shows the inside data and the current operating mode . The rear panel provide RS232 interface and 10/100 Ethernet interface , used in SNMP, long-distance control and management.
LTS-2000 has three operation modes:
1, ITU Grid 50GHz spacing fixed output wavelength:
Internal memory ITU Grid 50GHz spacing all channel data. Customers input standard ITU Grid code, frequency or wavelength ,in less than 20ms duration, The LTS-2000 can quick accurate lock and output the wavelength you choose.
2, C-Band or L-Band any fixed wavelength output. Any fixed-wavelength output.
3, Single or double wavelength / roundtrip frequency scanning:
Users set the wavelength range ,step ,rate ,single or double scanning to wavelength / toundtrip frequency .
The output power of LTS-2000-V can be setup by accuracy of 0.01dB.
1. Full C-Band or L-Band tunability
2. >35nm Tuning range ( C or L-Band)
3. ITU Grid 50GHz Spacing Locking ( C/L-Band>89CH )
4. Fast tuning speed ( 20ms )
5. High Wavelengths ( or Frequency ) accuracy
6. High Wavelengths ( or Frequency ) Stability
7. High Power/wavelengths ripple
8. High Output power ( >13dBm )
9. Settable Output Power
10. Narrow Linewidth
11. Superior SMSR
12. High OSNR ( >50dB )
13. Polarization maintaining optical fiber output optional
14. Colorful large screen, displays all kinds of parameter and control mode
15. RS232 Serial Communication intrface
16. RJ45 Ethernet intrface for SNMP remote control
17. Small model can be configured with 1~4 independent light source, Applicable to various test and measurement
18. Excellent P/P ratio
1. WDM Component testing & QA
2. Fiber sensors
3. PMD & PDL measurement s
4. Optical Coherence Tomography ( OCT )
5. AWQ & PLC Component testing
6. WDWM system testing and measurement
| Performance | Index | Supplement | |||
| Min. | Typ. | Max. | |||
| Tuning Range | (nm) | 35 | |||
| C-Band Frequency tuning Range | (nm) | 1528.77 | 1563.86 | LTS-2500 | |
| C-Band Wavelength tuning Range | (THz) | 191.7 | 196.1 | LTS-2500 | |
| L-Band Frequency tuning Range | (nm) | 1568.7 | 1607.5 | LTS-2600 | |
| L-Band Wavelength tuning Range | (THz) | 186.5 | 191.1 | LTS-2600 | |
| Number of ITU grid locking | 89 | C or L-Band50GHz spacing | |||
| Channels Spacing | (nm) | 0.4 | 50GHz spacing | ||
| Locked wavelength accuracy | (nm) | -0.014 | ± 0.01 | +0.014 | ± 1.8GHz |
| Wavelength stability | (nm) | -0.012 | ± 0.008 | +0.012 | ± 1.5GHz |
| Tuning Speed | (mS) | 10 | 20 | ||
| Power / wavelength ripple | (dB) | -0.25 | ±0.15 | +0.25 | Over tuning range |
| Output Optical Power | (dBm) | 13 | |||
| Output optical setting range | (dB) | +8 | +13 | LTS-2000-V | |
| Resolution for power setting | (dB) | 0.01 | LTS-2000-V | ||
| Line width | (MHz) | 1 | 5 | ||
| Side Mode Suppression ratio | (dB) | 45 | 50 | ||
| Relative Intensity Noise (RIN) | (dB) | -150 | -140 | ||
| OSNR | (dB) | 50 | 0.1nm Bandwidth | ||
| Polarization Extinction Ratio (PER) | (dB) | 20 | PMF | ||
| Return loss | (dB) | 50 | |||
| Model | CW | Continuous Wave | |||
| Optical connector | SC/APC | Optional FC/APC, LC/APC | |||
| 10/100M Ethernet interface | RJ45 | ||||
| Net working protocol | RJ45 | ||||
| Communication interface | RS232 | ||||
| Power supply | (VAC) | 90 | 265 | 50/60Hz | |
| Work temp. | ( °C ) | -5 | 65 | ||
| Storage temp. | ( °C ) | -40 | 85 | ||
| Relative humidity | (%) | 5 | 95 | ||
| Size (W)x(D)x(H) | ( " ) | 11×14×3.5 | |||
1. What are the payment terms of payment?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is more convenient for you.
2. What about the lead time?
Usually, if there's stock, we ship the goods within 5-7 working days after the deposit is confirmed. If it is out of stock, the lead time depends.
3. How about the shipping?
When the package is small, we will deliver the goods via international Express like FedEx , DHL,TNT and UPS and so on. Door to door delivery service will be provided; while the goods have high weight and volume, we suggest using air or sea shipment.
4. Can you do OEM for us?
Yes. if there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.
5. What are the advantages of your products?
A. Good quality and competitive prices
B. Strict quality control during production process.
C. Professional operations in processes of production, sales, assembling, packaging and shipping
D. Good after-sale service. Professional online technical support can be provided. Moreover, if there is any problem of the goods, we will help to solve the problem or provide replacement of the goods
6. How about the Warranty?
There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.
