42000L Heavy Duty 3 Axle Aluminum Fuel Tank Semi Trailer
Heavy Duty 3 Axle Aluminum Fuel Tank Semi Trailer Carbon Steel Fuel Tank semi Trailer Stainless Fuel Tank semi Trailer1 Applied Aluminium alloy that in accordance with the international standard. Thickness is 5-10mm.2 Apply the famous pump.3 The main parts implements automatic welding, while the acc......
Send Inquiry
Product Description
Heavy Duty 3 Axle Aluminum Fuel Tank Semi Trailer Carbon Steel Fuel Tank semi Trailer Stainless Fuel Tank semi Trailer
1 Applied Aluminium alloy that in accordance with the international standard. Thickness is 5-10mm.
2 Apply the famous pump.
3 The main parts implements automatic welding, while the accessories apply carbon dioxide welding to ensure the tank in good performance.
4 Sub crossbeam apply rectangle steel sheet that thickness more than 5mm, stick out in one time.
5 Fire extinguisher replaced on the back of the truck for the emergency.
6 Painting held more tolerance and coherence, can make sure the tank in good situation more than 5 years.
Chengli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special trucks and trailers as well as other special equipment.
1. We can supply all brands of special trucks, such as, Faw, Foton, Shaanxi, Sinotruck, JAC, JMC, Isuzu, Dongfeng.
2. Factory export department directly sale
3. Export experience more than 12 years
4. Cheap / competitive price, high quality, you get more than your paid
5. With CCC, ISO, BV approved
6. The heart of the service, rational design
Our main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
If you are interested in our trucks, pls contact me, I will send our best quotation to you.
1 Applied Aluminium alloy that in accordance with the international standard. Thickness is 5-10mm.
2 Apply the famous pump.
3 The main parts implements automatic welding, while the accessories apply carbon dioxide welding to ensure the tank in good performance.
4 Sub crossbeam apply rectangle steel sheet that thickness more than 5mm, stick out in one time.
5 Fire extinguisher replaced on the back of the truck for the emergency.
6 Painting held more tolerance and coherence, can make sure the tank in good situation more than 5 years.
Chengli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special trucks and trailers as well as other special equipment.
1. We can supply all brands of special trucks, such as, Faw, Foton, Shaanxi, Sinotruck, JAC, JMC, Isuzu, Dongfeng.
2. Factory export department directly sale
3. Export experience more than 12 years
4. Cheap / competitive price, high quality, you get more than your paid
5. With CCC, ISO, BV approved
6. The heart of the service, rational design
Our main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
If you are interested in our trucks, pls contact me, I will send our best quotation to you.
| Main Dimensions | |||||
| Overall Length | 11800mm | ||||
| Overall Height | 3700mm | ||||
| Tare Weight | 7000KGS | ||||
| Loading Capacity | 42 m3 | ||||
| Photo only for reference, final product can be made according to exact requirements | |||||
| Tank Body | |||||
| Shape | Mono block Cylinder | ||||
| Total Volume(m3) | 42CBM | ||||
| Tanker Body Material | 5mm 5083 aluminium alloy | ||||
| End plate | 6mm 5083 aluminium alloy | ||||
| Lifting Ladder | Including Top walkway and backside Aluminum material | ||||
| Manhole cover | Aluminum alloy API manhole cover, 500mm ,4 sets with 4 breather valves | ||||
| Bottom Valve | 4 sets of Aluminum API Pneumatic Bottom Valve,Pneumatic control | ||||
| Discharging valve | 4 set 100mm discharging valves, API standard | ||||
| No.of Compartment | 4 | ||||
| Discharging Pipe | 4"rubber hose, 2 pc, 6m long | ||||
| Chassis | |||||
| Main Beams | Special design I beam, connected by bolts and nuts with tanker body, removable from tanker body for separate transportation; | ||||
| Axle | 3 axles | ||||
| BPW 13 Ton | |||||
| Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear | ||||
| King Pin | JOST brand 2" bolt-in king pin | ||||
| Suspension | German design heavy duty mechanical suspension | ||||
| Pneumatic Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks. | ||||
| Wheel rim | 9.0-22.5 wheel rim, 13 pieces including one spare | ||||
| Tire | 12R22.5 tubeless tire with one spare tire, 13 pieces | ||||
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint | ||||
| Accessories | One standard tool box, 1X150L water tanker, 1X500L Spare Fuel Tanker | ||||
