China Made Sintruk Cdw 5 Ton Light Tipper Dump Truck
CDW 5 Ton Light Duty Front Tipping Extened Cabin Dump TruckSpecifications(1) 4x2 Light Duty Dump Truck.(2) 2 Axle(3) Loading Capacity 5 ton.(4) Fuel Consumption 15.5L per 100km.(5) Euro 1 emission.(6) Chassis Model CDW3050HA3P4.(7) Certification: ISO9001 CCC,SGSTechnical ParametersCabin 1760 mm exte......
Send Inquiry
Product Description
CDW 5 Ton Light Duty Front Tipping Extened Cabin Dump Truck
Specifications
(1) 4x2 Light Duty Dump Truck.
(2) 2 Axle
(3) Loading Capacity 5 ton.
(4) Fuel Consumption 15.5L per 100km.
(5) Euro 1 emission.
(6) Chassis Model CDW3050HA3P4.
(7) Certification: ISO9001 CCC,SGS
Technical Parameters
Our Advantage
1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as a manufacturer
3.Products Quality Certification SGS CCC ISO
4.Perfect after-sale service
5.Customized products available with us
6.Export to more than 50 countries and regions
7.Oversea wareshouse with more than 100000 US dollors spare parts in stock
8.Oversea office with more than 15 professional engineers to help local customers
Main products
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
FAQ
1. MOQ: 1 unit
2. Optional payment terms: T/T or L/C
T/T: 30% deposit by T/T, 70% balance should be paid before shippment.
L/C: 30% payment advance, 70% L/C at sight.
3. Parts of famous brand can be adopted by your requirement, such as WABCO, JOST, BPW, FUWA.
4. Delivery time: Within15 workdays after receiving 30% deposit of T/T
Warranty
1. One year quality guarantee for three key parts axles, engine, transmission or within 100000km, which comes the first.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.
Your are always welcome to visit our factory at any time.
Specifications
(1) 4x2 Light Duty Dump Truck.
(2) 2 Axle
(3) Loading Capacity 5 ton.
(4) Fuel Consumption 15.5L per 100km.
(5) Euro 1 emission.
(6) Chassis Model CDW3050HA3P4.
(7) Certification: ISO9001 CCC,SGS
Technical Parameters
| Cabin | 1760 mm extended cabin, radio FM with USB, LHD , photo for reference | |
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 571 0×2160×2610 |
| Wheel base (mm) | 3000 | |
| Wheel track (front/rear) (mm) | 1285/1425 | |
| Weight in KGS | Tare Weight | 5390 |
| Payload | 1995 | |
| Front axles loading capacity | 1x2500 | |
| Rear axles loading capacity | 1x2890 | |
| Max. driving speed(km/h) | 80 | |
| Engine | Brand | Yunnei |
| Model | YN490QB | |
| Type | Euro-1 emission, intercooler, turbocharge | |
| Horse Power | 65 HP | |
| Max Torque | 200 N.m | |
| Gearbox | 540Z, 5-forward & 1 reverse gear | |
| Brake | Dual circuit compressed air brake | |
| Steering | Power steering | |
| Chassis | Section 200x8 mm | |
| Tire | 7.50-16 tyre with one spare, rear axle with double tires, total 7pcs | |
| Axle | 1058S1X/1068Q(i=6.167) | |
| Cargo Body | 3340×1 900×600mm | |
| Lifting System | Twin-plunger straight propping up | |
| Hydraulic System | 90×70 mm | |
Our Advantage
1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as a manufacturer
3.Products Quality Certification SGS CCC ISO
4.Perfect after-sale service
5.Customized products available with us
6.Export to more than 50 countries and regions
7.Oversea wareshouse with more than 100000 US dollors spare parts in stock
8.Oversea office with more than 15 professional engineers to help local customers
Main products
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
FAQ
1. MOQ: 1 unit
2. Optional payment terms: T/T or L/C
T/T: 30% deposit by T/T, 70% balance should be paid before shippment.
L/C: 30% payment advance, 70% L/C at sight.
3. Parts of famous brand can be adopted by your requirement, such as WABCO, JOST, BPW, FUWA.
4. Delivery time: Within15 workdays after receiving 30% deposit of T/T
Warranty
1. One year quality guarantee for three key parts axles, engine, transmission or within 100000km, which comes the first.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.
Your are always welcome to visit our factory at any time.
