Beiben Ng80 6X4 340HP Dump Truck Tipper with Rhd
Beiben NG80 23 CBM 6x4 340HP RHD Heavy Duty Dump Truck with Mercedes Benz TechnologyDrive type: 6x4 Driving type: RHD Wheelbase: 4450mm+1450mm Engine: 340hp, Euro IIIOur BEIBEN truck factory was joint vent......
Send Inquiry
Product Description
Beiben NG80 23 CBM 6x4 340HP RHD Heavy Duty Dump Truck with Mercedes Benz Technology
Drive type: 6x4
Driving type: RHD
Wheelbase: 4450mm+1450mm
Engine: 340hp, Euro III
Our BEIBEN truck factory was joint venture company with German Mercedes-Benz truck before, so all our BEIBEN truck's technology is from Mercedes-Benz truck technology. Also our BEIBEN truck's axles is the same as Mercedes-Benz truck axle, and the axles spare parts are total the same as Mercedes-Benz truck axles. And 60% Chinese military trucks are using BEIBEN brand trucks.
Features & Benefits:
Beiben truck features and advantages:
1: Driving room: the steel structure, high safety, lower wind resistance coefficient
2: Power system dynamic matching technology of Mercedes-Benz: less power loss and more efficient
3: The suspension system: Mercedes suspension, high intensity
4: Benz axle: Double Deceleration Bridge, high efficiency, carrying large
5: Transmission system: high efficiency, bigger torque, climbing superior performance
6: Steering system: high safe and reliable, and flexible
7: Braking system, high security, brake with high efficiency
8: Electric system: stronger load ability, high reliability and easy maintenance.
Beiben truck is manufactured under the license of Mercedes Benz technology, which has excellent performance with reasonable price.
The series products of our trucks are ideal transport with outstanding performance and high quality, they are widely used in industries and sectors, such as national defense, aviation, postal service, railways, highways, harbors, petroleum, chemicals, water and electricity, forests, fire fighting, banks and peace keeping forces. Now our trucks are sold to the worldwide countries and areas.
Originate from Mercedes-Benz, Germany. The Chinese local manufacturers, technical performance properties index and conform to the state and military standard.
Specifications:
Dump body (20m3)
Drive type: 6x4
Driving type: RHD
Wheelbase: 4450mm+1450mm
Engine: 340hp, Euro III
Our BEIBEN truck factory was joint venture company with German Mercedes-Benz truck before, so all our BEIBEN truck's technology is from Mercedes-Benz truck technology. Also our BEIBEN truck's axles is the same as Mercedes-Benz truck axle, and the axles spare parts are total the same as Mercedes-Benz truck axles. And 60% Chinese military trucks are using BEIBEN brand trucks.
Features & Benefits:
Beiben truck features and advantages:
1: Driving room: the steel structure, high safety, lower wind resistance coefficient
2: Power system dynamic matching technology of Mercedes-Benz: less power loss and more efficient
3: The suspension system: Mercedes suspension, high intensity
4: Benz axle: Double Deceleration Bridge, high efficiency, carrying large
5: Transmission system: high efficiency, bigger torque, climbing superior performance
6: Steering system: high safe and reliable, and flexible
7: Braking system, high security, brake with high efficiency
8: Electric system: stronger load ability, high reliability and easy maintenance.
Beiben truck is manufactured under the license of Mercedes Benz technology, which has excellent performance with reasonable price.
The series products of our trucks are ideal transport with outstanding performance and high quality, they are widely used in industries and sectors, such as national defense, aviation, postal service, railways, highways, harbors, petroleum, chemicals, water and electricity, forests, fire fighting, banks and peace keeping forces. Now our trucks are sold to the worldwide countries and areas.
Originate from Mercedes-Benz, Germany. The Chinese local manufacturers, technical performance properties index and conform to the state and military standard.
Specifications:
| BEIBEN 6x4 Dump Truck | |
| Traction type | 6x4 |
| Driving type | RHD |
| Cabin | Mercedes Benz(NG80B), with A/C |
| Engine brand | Weichai |
| Engine model | 340HP |
| Engine type | Water-cooled, four-stoke, exhaust brake, direct injection, turcharged intercooled |
| Displacement | 9.726 liters |
| Max. output | 320hp@2,200rpm |
| Max torque | 1,250NM@1,400-1,600rpm |
| Bore/Stroke(mm) | 126/130 |
| Gear box | FAST 12JS160T (12 forward speeds + 2 reverse speeds) |
| Clutch | 430 Spring type |
| Steering | ZJ120D |
| Tyre | 12.00R20 |
| Spring | 10/13 |
| Max. speed (km/h) | 90 |
| Front axle | Mercedes-benz Axle, 7.5tons |
| Rear axle | Mercedes-benz Axle, double differential reduction, 13tons |
| Curb weight | 12,200kg |
| Total Mass | 25,000kg |
| Wheel base (mm) | 3,800+1,450 |
| Front track (mm) | 1,995 |
| Rear track (mm) | 1,800/1800 |
| Approach angle | 26 degree |
| Departure angle | 32 degree |
| Dimension (mm) | 9,000x2,500x3,400 |
| Internal Size | 23CBM, 6800x2300x1500mm |
| Thickness of body steel | Side 6mm & bottom 8mm |
| Tipping type | Front lift |
| Front type hydraulic system (HYVA hydraulic cylinder) | |
