Product Description

GENERAL DESCRIPTION

This oil press machine is suitable for the extraction of vegetable oils from such oil-bearing materials as rape seed,peanuts,sesame seed,etc.(The pressing worms can be replaced as required by the user for the purpose of the extraction of oils from some other oil-bearing materials,such as rice bran oil and the like.)

FEATURES

All such main parts of this oil press machine as worm shaft ,pressing worms,cage and so forth are made of high-grade alloy steel through hardening treatment.As a result,in spite of the conditions of high temperature and abrasion under which they work day and night,they keep durable for a considerable period.
The combination of steaming and roasting is also one of the features of this machine.It can be regulated in accordance with the varied requirements of various oil-bearing materials for the temperatures pressing so as to get high quality oils.

The whole process form feeding,steaming,roasting up to the discharge of oil and cake of this oil press goes on automatically and continuously,so it is easy to operate the machine,which results in the saving of labor.

Name	of oil	Capacity(kg/24hrs)	Oil yield(%)	Residual oil in dry
seed				cake(%)

Rape seed		9000-12000	33-38	6-7

Prsnuts		9000-10000	38-45	5-6

Sesame seed		6500-7500	42-47	7-7.5

Cotton beans		9000-10000	30-33	5-6

Soya beans		8000-9000	11-14	5-6

Sunflower		7000-8000	22-25	6-7
seed

Rice bran		6000-7000	10-14	6-7
