Product Description

The Description of Combine Rice Mill/Milling Machine

I. Structure: This machine is mainly composed of four parts including rice machine, pulverizer, motor and frame. The rice machine is composed of machine cover, middle seat, rice roller, rice sieve, huller blade,
feeder, separator, gravity sieve separator, belt wheel and adjusting device; The pulverizer is composed of
body shell, feed hopper and discharge hopper.

II. Usage: The milling part of the machine can process unhusked rice into rice in one lot and
simultaneously finish the separation of rice, bran and broken rice in one lot. The pulverizer can
be used to pulverize unhusked rice, corn, sorghum, beans, potato and stem, and so on.

III. Performance: This machine has many advantages, such as reasonable structure, compact
model, simple operation, convenient repairing, fast milled rice rate, less power consumption,
safety, reliability etc.

4n-4bd Diesel Version Combine Rice Mill

IV. Technical parameters

Overall Dimension(mm)	12704401150
Packing Size(mm)	750330590
Rated Power(KW)	2.2kw
Voltage(V)	220v
Motor Speed (R/Min)	2800
Total Weight (kg)	76kg
Productivity(kg/h)	Milling part≥180kg

V. Technical Parameters of Diesel Engine

Type	Single cylinder, vertical, Four - Stroke, Air cooled, Direct Injection
Cylinder Dia. × Stroke(mm)	70×59
Displacement(L)	0.227
Compression Ratio	20±1
Rated Power(Kw)	3.00/3000 3.50/3600
Rated Speed(r/min)	3000/3600
Start-up Mode	Recoil starting by hand or electric starting
Direction of Rotation	Anticlockwise(From the power output end)
Oil Tank Capacity(L)	2.5
Fuel Consumption Rate(g/kW.h)	≤288.3
Fuel Oil	0#(Summer)or-11#(Winter) Light Diesel Oil
Engine Oil Capacity(L)	0.75
Lubrication Oil	SAE10W31(CC Grade Above)
PTO Shaft	Camshaft or Bent Axle
Overall Dimension(L×W×H)(mm)	332×376×415
Net Weight(kg)	≤27
